Borewell Submersible Pumpsets
Domestic Borewell Submersible Pumpsets
4″ (100mm) V4
Product Descriptions
“NEC” 4″ STAINLESS STEEL SUBMERSIBLE PUMPSETS are easy to install, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain long life and facilitate easy service.
Performance Chart
Applications
- Water extraction from bores of diameter 4″ (100mm) and above
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Industrial water supply
Features
- Energy efficient motor
- Water filled motor with easily rewindable stator
- Suitable for single phase 220 V and three phase 380 V, 50 Hz power supplies
- Corrosion resistant stainless steel stator casing
- Energy efficient radial and mixed flow pumps
- Corrosion resistant high strength stainless steel impellers and diffusers
- Stainless steel stage housings
- Customized pumpsets are available on request
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Higher stage pumps are available in modular construction for ease of assembly,tranport and installation
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel |
PUMP | |
Pump shaft | Stainless steel |
Discharge casing | Stainless steel |
Inlet bracket | Stainless steel |
Diffuser assembly | Stainless steel |
Impeller | Stainless steel |
Strainer | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 4”and above |
Power Range | 0.5 to 7.5 HP |
Voltage Range | 220V- 240V, AC Single phase , 50Hz |
340V- 440V, AC Three phase , 50Hz | |
Speed | 2900RPM |
Motor Type | Water filled water cooled Induction motor |
Coupling | Key / NEC |
Head | Maximum 341 M |
Discharge | Maximum 12000 LPH |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 50 bar |
Sand content in water | Maximum 50 PPM |
Submersible Borewell Pumps
Domestic Submersible Borewell Pumpsets
4″ (100mm) 600feet
Product Descriptions
“NEC” 4″ STAINLESS STEEL SUBMERSIBLE PUMPSETS are easy to install, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain long life and facilitate easy service.
Performance Chart
Applications
- Water extraction from bores of diameter 4″ (100mm) and above
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Industrial water supply
Features
- Energy efficient motor
- Water filled motor with easily rewindable stator
- Suitable for single phase 220 V and three phase 380 V, 50 Hz power supplies
- Corrosion resistant stainless steel stator casing
- Energy efficient radial and mixed flow pumps
- Corrosion resistant high strength stainless steel impellers and diffusers
- Stainless steel stage housings
- Customized pumpsets are available on request
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Higher stage pumps are available in modular construction for ease of assembly,tranport and installation
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel |
PUMP | |
Pump shaft | Stainless steel |
Discharge casing | Stainless steel |
Inlet bracket | Stainless steel |
Diffuser assembly | Stainless steel |
Impeller | Stainless steel |
Strainer | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 4”and above |
Power Range | 0.5 to 7.5 HP |
Voltage Range | 220V- 240V, AC Single phase , 50Hz |
340V- 440V, AC Three phase , 50Hz | |
Speed | 2900RPM |
Motor Type | Water filled water cooled Induction motor |
Coupling | Key / NEC |
Head | Maximum 341 M |
Discharge | Maximum 12000 LPH |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 50 bar |
Sand content in water | Maximum 50 PPM |
Domestic Submersible Borewell Pumpsets
4″ (100mm) 1000feet
Product Descriptions
“NEC” 4″ STAINLESS STEEL SUBMERSIBLE PUMPSETS are easy to install, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain long life and facilitate easy service.
Performance Chart
Applications
- Water extraction from bores of diameter 4″ (100mm) and above
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Industrial water supply
Features
- Energy efficient motor
- Water filled motor with easily rewindable stator
- Suitable for single phase 220 V and three phase 380 V, 50 Hz power supplies
- Corrosion resistant stainless steel stator casing
- Energy efficient radial and mixed flow pumps
- Corrosion resistant high strength stainless steel impellers and diffusers
- Stainless steel stage housings
- Customized pumpsets are available on request
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Higher stage pumps are available in modular construction for ease of assembly,tranport and installation
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel |
PUMP | |
Pump shaft | Stainless steel |
Discharge casing | Stainless steel |
Inlet bracket | Stainless steel |
Diffuser assembly | Stainless steel |
Impeller | Stainless steel |
Strainer | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 4”and above |
Power Range | 0.5 to 7.5 HP |
Voltage Range | 220V- 240V, AC Single phase , 50Hz |
340V- 440V, AC Three phase , 50Hz | |
Speed | 2900RPM |
Motor Type | Water filled water cooled Induction motor |
Coupling | Key / NEC |
Head | Maximum 341 M |
Discharge | Maximum 12000 LPH |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 50 bar |
Sand content in water | Maximum 50 PPM |
Domestic Submersible Monobloc Borewell Pumpsets H36 Model
4″ (100mm) 120Feet
Product Descriptions
“NEC” 4″ STAINLESS STEEL SUBMERSIBLE PUMPSETS are easy to install, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain long life and facilitate easy service.
Applications
- Water extraction from bores of diameter 4″ (100mm) and above
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Industrial water supply
Features
- Energy efficient motor
- Water filled motor with easily rewindable stator
- Suitable for single phase 220 V and three phase 380 V, 50 Hz power supplies
- Corrosion resistant stainless steel stator casing
- Energy efficient radial and mixed flow pumps
- Corrosion resistant high strength stainless steel impellers and diffusers
- Stainless steel stage housings
- Customized pumpsets are available on request
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Higher stage pumps are available in modular construction for ease of assembly,tranport and installation
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel |
PUMP | |
Pump shaft | Stainless steel |
Discharge casing | Stainless steel |
Inlet bracket | Stainless steel |
Diffuser assembly | Stainless steel |
Impeller | Stainless steel |
Strainer | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 4”and above |
Power Range | 0.5 to 7.5 HP |
Voltage Range | 220V- 240V, AC Single phase , 50Hz |
340V- 440V, AC Three phase , 50Hz | |
Speed | 2900RPM |
Motor Type | Water filled water cooled Induction motor |
Coupling | Key / NEC |
Head | Maximum 341 M |
Discharge | Maximum 12000 LPH |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 50 bar |
Sand content in water | Maximum 50 PPM |
Submersible Borewell Pumpsets
Domestic Submersible Borewell Pumpsets
3″ (75mm) 500Feet
Product Descriptions
“NEC” 3″ SUBMERSIBLE PUMPSETS are easy to install, noise free, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain long life and provide easy service.
Applications
- Water extraction from bores of diameter 3″ (80mm) and above
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Domestic water supply to large residential and multi-storied apartments
- Garden irrigation including Drip & Sprinkler systems
- Pressure boosting applications
Features
- Energy efficient motor
- Water filled motor with easily rewindable stator
- Suitable for single phase 220 V, 50 Hz power supplies
- Corrosion resistant stainless steel stator casing
- Energy efficient radial flow pumps
- Wear resistant high strength engineering polymer impellers and diffusers with stainless steel inserts
- Stainless steel stage housings / Stainless steel pump shell
- Customized pumpsets are available on request
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
Material of construction
PARTICULARS | DETAILS |
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with SS segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel |
Strainers | Stainless steel |
PUMP | |
Pump shaft | Stainless steel |
Discharge casing | Cast Iron / Bronze |
Inlet bracket | Cast Iron / Bronze |
Diffuser assembly | Engineering Plastic |
Impeller | Engineering Plastic |
Pump shell | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 3”and above |
Power Range | 0.5 to 1.5 HP |
Voltage Range | 220V- 240V, AC Single phase , 50Hz |
Speed | 2900 RPM |
Motor Type | Wet Type water filled water cooled Induction motor |
Coupling | Key / NEMA |
Head | Maximum 83 M |
Discharge | Maximum 5500 LPH |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 20 bar |
Sand content in water | Maximum 50 PPM |
Submersible Borewell Pumpsets
Agricultural Borewell Submersible Pumpsets
6″ (150mm) 1300Feet
Product Descriptions
“NEC” “6″ SUBMERSIBLE PUMPSETS are easy to install, noise free, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain a reliable life and provide maintenance free service.
Performance Chart
Applications
- Water extraction from bores of diameter 6″ (150mm) and above
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Dewatering of mines
- Industrial water supply
Features
- Energy efficient motor
- Usage of Low watt In-house Manufactured Stampings
- Low operating cost (Low Power Consumption)
- Water lubricated motor with easily rewindable stator
- Energy Efficient Radial and mixed flow models
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Wide voltage operation to suit all seasons
- Low, Medium, High Voltage operation Motors to suit particular field condition
- Pumpsets with special materials are available on request
Material of Constructions
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitrile Rubber |
Shaft | Carbon steel with SS extension |
Strainers | Stainless steel |
PUMP | ||
Pump shaft | Stainless steel | Stainless steel |
Valve casing | Cast Iron | Cast Iron |
Inlet bracket | Cast Iron | Cast Iron |
Diffuser housing | Cast Iron | Cast Iron |
Diff user | Bronze / SS | Stainless steel |
Bowl | Cast Iron | Cast Iron |
Impeller | Bronze / SS | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 6”and above |
Power Range | 2.0 to 30.0 HP |
Voltage Range | 340V- 440V, AC Three phase , 50Hz |
Voltage Range | 180V – 240V, AC Single phase , 50Hz (Upto 7.5 HP) |
Speed | 2900 RPM |
Motor Type | Water filled and water cooled Induction motor |
Coupling | Key ( Upto 25 HP) / NEC |
Head | Maximum 400 M |
Discharge | Maximum 600 LPM |
No of Stages | Maximum 25 |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 50 bar |
Sand content in water | 50 PPM Max. |
Pump Models | AT,JT,AT-SS |
Motor Models | ST/NST/EMS/EMS* |
Submersible Borewell Pumpsets
Agricultural Borewell Submersible Pumpsets
6″ (150mm) 1300Feet
Product Descriptions
“NEC” “6″ SUBMERSIBLE PUMPSETS are easy to install, noise free, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain a reliable life and provide maintenance free service.
Performance Chart
Applications
- Water extraction from bores of diameter 6″ (150mm) and above
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Dewatering of mines
- Industrial water supply
Features
- Energy efficient motor
- Usage of Low watt In-house Manufactured Stampings
- Low operating cost (Low Power Consumption)
- Water lubricated motor with easily rewindable stator
- Energy Efficient Radial and mixed flow models
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Wide voltage operation to suit all seasons
- Low, Medium, High Voltage operation Motors to suit particular field condition
- Pumpsets with special materials are available on request
Material of Constructions
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitrile Rubber |
Shaft | Carbon steel with SS extension |
Strainers | Stainless steel |
PUMP | ||
Pump shaft | Stainless steel | Stainless steel |
Valve casing | Cast Iron | Cast Iron |
Inlet bracket | Cast Iron | Cast Iron |
Diffuser housing | Cast Iron | Cast Iron |
Diff user | Bronze / SS | Stainless steel |
Bowl | Cast Iron | Cast Iron |
Impeller | Bronze / SS | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 6”and above |
Power Range | 2.0 to 30.0 HP |
Voltage Range | 340V- 440V, AC Three phase , 50Hz |
Voltage Range | 180V – 240V, AC Single phase , 50Hz (Upto 7.5 HP) |
Speed | 2900 RPM |
Motor Type | Water filled and water cooled Induction motor |
Coupling | Key ( Upto 25 HP) / NEC |
Head | Maximum 400 M |
Discharge | Maximum 600 LPM |
No of Stages | Maximum 25 |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 50 bar |
Sand content in water | 50 PPM Max. |
Pump Models | AT,JT,AT-SS |
Motor Models | ST/NST/EMS/EMS* |
Domestic Openwell Submersible Pumpsets
Eco Model
Product Description
“NEC” SINGLE PHASE OPEN WELL SUBMERSIBLE PUMPSETS offer the convenience of not having to change the position of the pump with changing water levels in the well. They are rugged and efficient.
Performance Chart
Applications
- Suitable for water pumping from sump, water tank & fountains
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Gardening and small farm Irrigations
- Home Pressure Boosting Applications
Features
- Energy efficient motor
- Low operating cost
- Fitted with Carbon Bushes
- Water lubricated motor with easily rewindable stator
- Rigid cast iron motor frame, impeller and volute casing
- Optional bronze impeller on request
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | Water-filled Squirrel cage Induction motor |
Stator Frame | Cast Iron (FG 200) / Stainless Steel |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Carbon |
Shaft | Stainless steel shaft with integral Sleeve |
Strainers | Stainless steel / PVC |
Discharge casing | Cast Iron (FG 200) |
Suction bracket | Cast Iron (FG 200) /PVC |
Cast Iron (FG 200) (Optional – Bronze) | |
Impeller | Stainless Steel (Fabricated) |
Range of Performance
PARTICULARS | DETAILS |
Power Range | 1.0 to 7.5 HP |
Voltage Range | 200V- 240V, AC Single phase , 50Hz |
Speed | 2900 RPM |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 42M |
Discharge | Maximum 700 LPM |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 10 bar |
Sand content in water | Maximum 50 PPM |
Submersible Pumpsets
Openwell Submersible Pumpsets
Domestic Openwell Submersible Pumpsets
Prime Model
Product Description
“NEC” SINGLE PHASE OPEN WELL SUBMERSIBLE PUMPSETS offer the convenience of not having to change the position of the pump with changing water levels in the well. They are rugged and efficient.
Performance Chart
Applications
- Suitable for water pumping from sump, water tank & fountains
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Gardening and small farm Irrigations
- Home Pressure Boosting Applications
Features
- Energy efficient motor
- Low operating cost
- Fitted with Carbon Bushes
- Water lubricated motor with easily rewindable stator
- Rigid cast iron motor frame, impeller and volute casing
- Optional bronze impeller on request
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | Water-filled Squirrel cage Induction motor |
Stator Frame | Cast Iron (FG 200) / Stainless Steel |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Carbon |
Shaft | Stainless steel shaft with integral Sleeve |
Strainers | Stainless steel / PVC |
Discharge casing | Cast Iron (FG 200) |
Suction bracket | Cast Iron (FG 200) /PVC |
Cast Iron (FG 200) (Optional – Bronze) | |
Impeller | Stainless Steel (Fabricated) |
Range of Performance
PARTICULARS | DETAILS |
Power Range | 1.0 to 7.5 HP |
Voltage Range | 200V- 240V, AC Single phase , 50Hz |
Speed | 2900 RPM |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 42M |
Discharge | Maximum 700 LPM |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 10 bar |
Sand content in water | Maximum 50 PPM |
Openwell Submersible Pumpsets
Three Phase Openwell Submersible Pumpsets
Agricultural Openwell Submersible Pumpsets
Product Description
“NEC” OPENWELL SUBMERSIBLE PUMPSETS offer the convenience of not having to change the position of the pump with changing water levels in the well. They are rugged and efficient. They are reliable and are built to withstand tough operating conditions like low voltages, etc.
Performance Chart
Applications
- Deep or shallow openwell pumping with suction lift
- River and canal lift irrigation pumping
- Pressure boosting applications.
- Public water supply to large residence areas and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals etc
- Dewatering of mines
- Industrial water supply and transfer
- Fountains
Features
- Energy efficient motor
- Low operating cost
- Rigid cast iron motor frame, impeller and volute casing
- Three phase water-filled submersible induction motor with easily rewindable stator
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | Water-filled Squirrel cage Induction motor |
Stator Frame | Cast Iron (FG 200) |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Phosphor Bronze / Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel shaft with integral sleeve /Carbon Steel shaft with SS sleeve |
Strainers | Stainless steel |
Discharge casing | Cast Iron (FG 200) |
Suction bracket | Cast Iron (FG 200) |
Impeller | Cast Iron (FG 200) (Optional – Bronze) |
Range of performance
PARTICULARS | DETAILS |
Power Range | 3.0 to 30.0 HP |
Voltage Range | 340V- 440V, AC Three phase , 50Hz |
Speed (rpm) | 2900 |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 90 m |
Discharge | Maximum 2640 lpm |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 20 bar |
Sand content | maximum ,50 PPM |
Openwell Submersible Pumpsets
Three Phase Openwell Submersible Pumpsets
Agricultural Openwell Submersible Pumpsets
Product Description
“NEC” OPENWELL SUBMERSIBLE PUMPSETS offer the convenience of not having to change the position of the pump with changing water levels in the well. They are rugged and efficient. They are reliable and are built to withstand tough operating conditions like low voltages, etc.
Performance Chart
Applications
- Deep or shallow openwell pumping with suction lift
- River and canal lift irrigation pumping
- Pressure boosting applications.
- Public water supply to large residence areas and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals etc
- Dewatering of mines
- Industrial water supply and transfer
- Fountains
Features
- Energy efficient motor
- Low operating cost
- Rigid cast iron motor frame, impeller and volute casing
- Three phase water-filled submersible induction motor with easily rewindable stator
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | Water-filled Squirrel cage Induction motor |
Stator Frame | Cast Iron (FG 200) |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Phosphor Bronze / Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel shaft with integral sleeve /Carbon Steel shaft with SS sleeve |
Strainers | Stainless steel |
Discharge casing | Cast Iron (FG 200) |
Suction bracket | Cast Iron (FG 200) |
Impeller | Cast Iron (FG 200) (Optional – Bronze) |
Range of performance
PARTICULARS | DETAILS |
Power Range | 3.0 to 30.0 HP |
Voltage Range | 340V- 440V, AC Three phase , 50Hz |
Speed (rpm) | 2900 |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 90 m |
Discharge | Maximum 2640 lpm |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 20 bar |
Sand content | maximum ,50 PPM |
Openwell Submersible Pumpsets
Three Phase Openwell Submersible Pumpsets
Agricultural Openwell Submersible Pumpsets
Product Description
“NEC” OPENWELL SUBMERSIBLE PUMPSETS offer the convenience of not having to change the position of the pump with changing water levels in the well. They are rugged and efficient. They are reliable and are built to withstand tough operating conditions like low voltages, etc.
Performance Chart
Applications
- Deep or shallow openwell pumping with suction lift
- River and canal lift irrigation pumping
- Pressure boosting applications.
- Public water supply to large residence areas and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals etc
- Dewatering of mines
- Industrial water supply and transfer
- Fountains
Features
- Energy efficient motor
- Low operating cost
- Rigid cast iron motor frame, impeller and volute casing
- Three phase water-filled submersible induction motor with easily rewindable stator
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | Water-filled Squirrel cage Induction motor |
Stator Frame | Cast Iron (FG 200) |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Phosphor Bronze / Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel shaft with integral sleeve /Carbon Steel shaft with SS sleeve |
Strainers | Stainless steel |
Discharge casing | Cast Iron (FG 200) |
Suction bracket | Cast Iron (FG 200) |
Impeller | Cast Iron (FG 200) (Optional – Bronze) |
Range of performance
PARTICULARS | DETAILS |
Power Range | 3.0 to 30.0 HP |
Voltage Range | 340V- 440V, AC Three phase , 50Hz |
Speed (rpm) | 2900 |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 90 m |
Discharge | Maximum 2640 lpm |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 20 bar |
Sand content | maximum ,50 PPM |
Openwell Submersible Pumpsets
Three Phase Openwell Submersible Pumpsets
Agricultural Openwell Submersible Pumpsets
Product Descriptions
“NEC” Vertical Open-well Submersible pumpsets are easy to install noise free, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operation requirements.
Performance Chart
Vertical Openwell Submersible Pumpsets Three Phase 380 To 415 Volts 50 HZ AC Supply
Applications
- Deep or shallow openwell pumping
- River and canal lift irrigation pumping.
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting Applications
- Public water supply to large residence areas and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Dewatering of mines
- Industrial water supply and transfer
Features
- Energy Efficient motors
- Low operating cost
- Water lubricated motor with easily rewindable stator
- Rigid cast iron motor frame, impeller and volute casing
- Optional bronze impeller on request
- Three phase water-filled submersible induction motor with easily rewindable stator
Material of Constructions
PARTICULARS | DETAILS |
Stator Frame | Cast Iron |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Phosphor Bronze / Carbon / Stainless steel |
Diaphragm | Nitrile Rubber |
Shaft | Stainless steel shaft with integral sleeve |
Strainers | Stainless steel |
Discharge casing | Cast Iron |
Inlet bracket | Cast Iron |
Impeller | Cast Iron / Bronze |
Range of Performance
PARTICULARS | DETAILS |
Power Range | 3.0 to 50.0 HP |
Voltage Range | 340V- 440V, 50Hz AC Three phase |
Speed | 2900RPM |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 128 M |
Discharge | Maximum 3190 LPM |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 20 bar |
Sand Content in Water | Maximum 50 PPM |
Openwell Submersible Pumpsets
Agricultural Openwell Vertical Submersible Pumpsets
Stainless Steel
Product Descriptions
“NEC” Vertical Open-well Submersible pumpsets are easy to install noise free, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operation requirements.
Applications
- Deep or shallow openwell pumping with suction lift
- River and canal lift irrigation pumping
- Pressure boosting applications.
- Public water supply to large residence areas and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals etc
- Dewatering of mines
- Industrial water supply and transfer
- Fountains
Features
- Energy efficient motor
- Low operating cost
- Rigid cast iron motor frame, impeller and volute casing
- Three phase water-filled submersible induction motor with easily rewindable stator
Material of Constructions
PARTICULARS | DETAILS |
Stator Frame | Cast Iron |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Phosphor Bronze / Carbon / Stainless steel |
Diaphragm | Nitrile Rubber |
Shaft | Stainless steel shaft with integral sleeve |
Strainers | Stainless steel |
Discharge casing | Cast Iron |
Inlet bracket | Cast Iron |
Impeller | Cast Iron / Bronze |
Range of Performance
PARTICULARS | DETAILS |
Power Range | 3.0 to 10.0 HP |
Voltage Range | 340V- 440V, 50Hz AC Three phase |
Speed | 2900RPM |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 60 M |
Discharge | Maximum 800 LPM |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 20 bar |
Sand Content in Water | Maximum 50 PPM |
Features
- Energy efficient motor
- Usage of Low watt In-house Manufactured Stampings
- Low operating cost (Low Power Consumption)
- Water lubricated motor with easily rewindable stator
- Energy Efficient Radial and mixed flow models
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Wide voltage operation to suit all seasons
- Low, Medium, High Voltage operation Motors to suit particular field condition
- Pumpsets with special materials are available on request
Material of Constructions
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitrile Rubber |
Shaft | Carbon steel with SS extension |
Strainers | Stainless steel |
PUMP | ||
Pump shaft | Stainless steel | Stainless steel |
Valve casing | Cast Iron | Cast Iron |
Inlet bracket | Cast Iron | Cast Iron |
Diffuser housing | Cast Iron | Cast Iron |
Diff user | Bronze / SS | Stainless steel |
Bowl | Cast Iron | Cast Iron |
Impeller | Bronze / SS | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 6”and above |
Power Range | 2.0 to 30.0 HP |
Voltage Range | 340V- 440V, AC Three phase , 50Hz |
Voltage Range | 180V – 240V, AC Single phase , 50Hz (Upto 7.5 HP) |
Speed | 2900 RPM |
Motor Type | Water filled and water cooled Induction motor |
Coupling | Key ( Upto 25 HP) / NEC |
Head | Maximum 400 M |
Discharge | Maximum 600 LPM |
No of Stages | Maximum 25 |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 50 bar |
Sand content in water | 50 PPM Max. |
Pump Models | AT,JT,AT-SS |
Motor Models | ST/NST/EMS/EMS* |
NEC Stainless steel Bore well submersibles pumps are suitable for corrosive environments. The weight to power ratio of these pumps is very low compared to conventional cast iron pumps. This facilitates easy handling and low installation cost. The submersible pump unit consists of a centrifugal wet end with one or more impellers with a strainer protected inlet bracket.
We bring forth a huge assortment of Borewell Submersibles for the worldwide clients. Made using superior quality material, our Deep Well Submersibles comply with industrial standards. Our Borewell Submersibles meet all your borehole pumping needs replacing standard surface pumps.
Salient Features
- Water filled motor with easily rewind able stator
- Suitable for various power supplies
- Energy efficient radial and mixed flow models
- Stainless steel stage housings
- Resistant to wearing
- Corrosion resistant
- Energy efficient
- Customized pump sets are available on request
Useful For
- Farming
- Irrigation
- Water supply
The 3″, 4″ Borewell Submersible we manufacture is a perfect blend of technology and high speed. Our 3″, 4″ Borewell Submersibles are praised for offering reliable and efficient performance. The 3″, 4″ Borewell Submersibles offered by us are high on demand in irrigation sector and can be availed at industry leading prices.
We are offering superior quality 5″, 6″, 7″, 8″, 10″ Borewell Submersibles that are made using high grade raw material. The 5″, 6″, 7″, 8″, 10″ Borewell Submersibles offered by us have been proved useful for the farming industry and are designed din compliance with international standards.
Applications:
Submersible pumps are found in many applications. Single stage pumps are used for drainage, sewage pumping, general industrial pumping and slurry pumping. They are also popular with pond filters. Multiple stage submersible pumps are typically lowered down a borehole and most typically used for residential, commercial, municipal and industrial water extraction (abstraction), water wells and in oil wells.
Other uses for submersible pumps include sewage treatment plants, seawater handling, fire fighting (since it is flame retardant cable), water well and deep well drilling, offshore drilling rigs, artificial lifts, mine dewatering, and irrigation systems.
Pumps in electrical hazardous locations used for combustible liquids or for water that may be contaminated with combustible liquids must be designed not to ignite the liquid or vapors.
Submersible Openwell Pumpsets Manufactures
Openwell Submersible Pumpsets
Submersible Borewell Pumpsets
Domestic Borewell Submersible Pumpsets
4″ (100mm)
Product Descriptions
“NEC” 4″ STAINLESS STEEL SUBMERSIBLE PUMPSETS are easy to install, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain long life and facilitate easy service.
Performance Chart
Applications
- Water extraction from bores of diameter 4″ (100mm) and above
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Industrial water supply
Features
- Energy efficient motor
- Water filled motor with easily rewindable stator
- Suitable for single phase 220 V and three phase 380 V, 50 Hz power supplies
- Corrosion resistant stainless steel stator casing
- Energy efficient radial and mixed flow pumps
- Corrosion resistant high strength stainless steel impellers and diffusers
- Stainless steel stage housings
- Customized pumpsets are available on request
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Higher stage pumps are available in modular construction for ease of assembly,tranport and installation
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel |
PUMP | |
Pump shaft | Stainless steel |
Discharge casing | Stainless steel |
Inlet bracket | Stainless steel |
Diffuser assembly | Stainless steel |
Impeller | Stainless steel |
Strainer | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 4”and above |
Power Range | 0.5 to 7.5 HP |
Voltage Range | 220V- 240V, AC Single phase , 50Hz |
340V- 440V, AC Three phase , 50Hz | |
Speed | 2900RPM |
Motor Type | Water filled water cooled Induction motor |
Coupling | Key / NEC |
Head | Maximum 341 M |
Discharge | Maximum 12000 LPH |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 50 bar |
Sand content in water | Maximum 50 PPM |
Submersible Borewell Pumps
Domestic Submersible Borewell Pumpsets
4″ (100mm) 600feet
Product Descriptions
“NEC” 4″ STAINLESS STEEL SUBMERSIBLE PUMPSETS are easy to install, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain long life and facilitate easy service.
Performance Chart
Applications
- Water extraction from bores of diameter 4″ (100mm) and above
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Industrial water supply
Features
- Energy efficient motor
- Water filled motor with easily rewindable stator
- Suitable for single phase 220 V and three phase 380 V, 50 Hz power supplies
- Corrosion resistant stainless steel stator casing
- Energy efficient radial and mixed flow pumps
- Corrosion resistant high strength stainless steel impellers and diffusers
- Stainless steel stage housings
- Customized pumpsets are available on request
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Higher stage pumps are available in modular construction for ease of assembly,tranport and installation
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel |
PUMP | |
Pump shaft | Stainless steel |
Discharge casing | Stainless steel |
Inlet bracket | Stainless steel |
Diffuser assembly | Stainless steel |
Impeller | Stainless steel |
Strainer | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 4”and above |
Power Range | 0.5 to 7.5 HP |
Voltage Range | 220V- 240V, AC Single phase , 50Hz |
340V- 440V, AC Three phase , 50Hz | |
Speed | 2900RPM |
Motor Type | Water filled water cooled Induction motor |
Coupling | Key / NEC |
Head | Maximum 341 M |
Discharge | Maximum 12000 LPH |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 50 bar |
Sand content in water | Maximum 50 PPM |
Domestic Submersible Borewell Pumpsets
4″ (100mm) 1000feet
Product Descriptions
“NEC” 4″ STAINLESS STEEL SUBMERSIBLE PUMPSETS are easy to install, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain long life and facilitate easy service.
Performance Chart
Applications
- Water extraction from bores of diameter 4″ (100mm) and above
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Industrial water supply
Features
- Energy efficient motor
- Water filled motor with easily rewindable stator
- Suitable for single phase 220 V and three phase 380 V, 50 Hz power supplies
- Corrosion resistant stainless steel stator casing
- Energy efficient radial and mixed flow pumps
- Corrosion resistant high strength stainless steel impellers and diffusers
- Stainless steel stage housings
- Customized pumpsets are available on request
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Higher stage pumps are available in modular construction for ease of assembly,tranport and installation
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel |
PUMP | |
Pump shaft | Stainless steel |
Discharge casing | Stainless steel |
Inlet bracket | Stainless steel |
Diffuser assembly | Stainless steel |
Impeller | Stainless steel |
Strainer | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 4”and above |
Power Range | 0.5 to 7.5 HP |
Voltage Range | 220V- 240V, AC Single phase , 50Hz |
340V- 440V, AC Three phase , 50Hz | |
Speed | 2900RPM |
Motor Type | Water filled water cooled Induction motor |
Coupling | Key / NEC |
Head | Maximum 341 M |
Discharge | Maximum 12000 LPH |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 50 bar |
Sand content in water | Maximum 50 PPM |
Domestic Submersible Monobloc Borewell Pumpsets H36 Model
4″ (100mm) 120Feet
Product Descriptions
“NEC” 4″ STAINLESS STEEL SUBMERSIBLE PUMPSETS are easy to install, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain long life and facilitate easy service.
Applications
- Water extraction from bores of diameter 4″ (100mm) and above
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Industrial water supply
Features
- Energy efficient motor
- Water filled motor with easily rewindable stator
- Suitable for single phase 220 V and three phase 380 V, 50 Hz power supplies
- Corrosion resistant stainless steel stator casing
- Energy efficient radial and mixed flow pumps
- Corrosion resistant high strength stainless steel impellers and diffusers
- Stainless steel stage housings
- Customized pumpsets are available on request
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Higher stage pumps are available in modular construction for ease of assembly,tranport and installation
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel |
PUMP | |
Pump shaft | Stainless steel |
Discharge casing | Stainless steel |
Inlet bracket | Stainless steel |
Diffuser assembly | Stainless steel |
Impeller | Stainless steel |
Strainer | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 4”and above |
Power Range | 0.5 to 7.5 HP |
Voltage Range | 220V- 240V, AC Single phase , 50Hz |
340V- 440V, AC Three phase , 50Hz | |
Speed | 2900RPM |
Motor Type | Water filled water cooled Induction motor |
Coupling | Key / NEC |
Head | Maximum 341 M |
Discharge | Maximum 12000 LPH |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 50 bar |
Sand content in water | Maximum 50 PPM |
Submersible Borewell Pumpsets
Domestic Submersible Borewell Pumpsets
3″ (75mm) 500Feet
Product Descriptions
“NEC” 3″ SUBMERSIBLE PUMPSETS are easy to install, noise free, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain long life and provide easy service.
Applications
- Water extraction from bores of diameter 3″ (80mm) and above
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Domestic water supply to large residential and multi-storied apartments
- Garden irrigation including Drip & Sprinkler systems
- Pressure boosting applications
Features
- Energy efficient motor
- Water filled motor with easily rewindable stator
- Suitable for single phase 220 V, 50 Hz power supplies
- Corrosion resistant stainless steel stator casing
- Energy efficient radial flow pumps
- Wear resistant high strength engineering polymer impellers and diffusers with stainless steel inserts
- Stainless steel stage housings / Stainless steel pump shell
- Customized pumpsets are available on request
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
Material of construction
PARTICULARS | DETAILS |
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with SS segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel |
Strainers | Stainless steel |
PUMP | |
Pump shaft | Stainless steel |
Discharge casing | Cast Iron / Bronze |
Inlet bracket | Cast Iron / Bronze |
Diffuser assembly | Engineering Plastic |
Impeller | Engineering Plastic |
Pump shell | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 3”and above |
Power Range | 0.5 to 1.5 HP |
Voltage Range | 220V- 240V, AC Single phase , 50Hz |
Speed | 2900 RPM |
Motor Type | Wet Type water filled water cooled Induction motor |
Coupling | Key / NEMA |
Head | Maximum 83 M |
Discharge | Maximum 5500 LPH |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 20 bar |
Sand content in water | Maximum 50 PPM |
Domestic Openwell Submersible Pumpsets
Eco Model
Product Description
“NEC” SINGLE PHASE OPEN WELL SUBMERSIBLE PUMPSETS offer the convenience of not having to change the position of the pump with changing water levels in the well. They are rugged and efficient.
Performance Chart
Applications
- Suitable for water pumping from sump, water tank & fountains
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Gardening and small farm Irrigations
- Home Pressure Boosting Applications
Features
- Energy efficient motor
- Low operating cost
- Fitted with Carbon Bushes
- Water lubricated motor with easily rewindable stator
- Rigid cast iron motor frame, impeller and volute casing
- Optional bronze impeller on request
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | Water-filled Squirrel cage Induction motor |
Stator Frame | Cast Iron (FG 200) / Stainless Steel |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Carbon |
Shaft | Stainless steel shaft with integral Sleeve |
Strainers | Stainless steel / PVC |
Discharge casing | Cast Iron (FG 200) |
Suction bracket | Cast Iron (FG 200) /PVC |
Cast Iron (FG 200) (Optional – Bronze) | |
Impeller | Stainless Steel (Fabricated) |
Range of Performance
PARTICULARS | DETAILS |
Power Range | 1.0 to 7.5 HP |
Voltage Range | 200V- 240V, AC Single phase , 50Hz |
Speed | 2900 RPM |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 42M |
Discharge | Maximum 700 LPM |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 10 bar |
Sand content in water | Maximum 50 PPM |
Submersible Pumpsets
Openwell Submersible Pumpsets
Domestic Openwell Submersible Pumpsets
Prime Model
Product Description
“NEC” SINGLE PHASE OPEN WELL SUBMERSIBLE PUMPSETS offer the convenience of not having to change the position of the pump with changing water levels in the well. They are rugged and efficient.
Performance Chart
Applications
- Suitable for water pumping from sump, water tank & fountains
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Gardening and small farm Irrigations
- Home Pressure Boosting Applications
Features
- Energy efficient motor
- Low operating cost
- Fitted with Carbon Bushes
- Water lubricated motor with easily rewindable stator
- Rigid cast iron motor frame, impeller and volute casing
- Optional bronze impeller on request
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | Water-filled Squirrel cage Induction motor |
Stator Frame | Cast Iron (FG 200) / Stainless Steel |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Carbon |
Shaft | Stainless steel shaft with integral Sleeve |
Strainers | Stainless steel / PVC |
Discharge casing | Cast Iron (FG 200) |
Suction bracket | Cast Iron (FG 200) /PVC |
Cast Iron (FG 200) (Optional – Bronze) | |
Impeller | Stainless Steel (Fabricated) |
Range of Performance
PARTICULARS | DETAILS |
Power Range | 1.0 to 7.5 HP |
Voltage Range | 200V- 240V, AC Single phase , 50Hz |
Speed | 2900 RPM |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 42M |
Discharge | Maximum 700 LPM |
Liquid temperature | Maximum 33ºC |
Operating Pressure | Maximum 10 bar |
Sand content in water | Maximum 50 PPM |
Openwell Submersible Pumpsets
Three Phase Openwell Submersible Pumpsets
Agricultural Openwell Submersible Pumpsets
Product Description
“NEC” OPENWELL SUBMERSIBLE PUMPSETS offer the convenience of not having to change the position of the pump with changing water levels in the well. They are rugged and efficient. They are reliable and are built to withstand tough operating conditions like low voltages, etc.
Performance Chart
Applications
- Deep or shallow openwell pumping with suction lift
- River and canal lift irrigation pumping
- Pressure boosting applications.
- Public water supply to large residence areas and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals etc
- Dewatering of mines
- Industrial water supply and transfer
- Fountains
Features
- Energy efficient motor
- Low operating cost
- Rigid cast iron motor frame, impeller and volute casing
- Three phase water-filled submersible induction motor with easily rewindable stator
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | Water-filled Squirrel cage Induction motor |
Stator Frame | Cast Iron (FG 200) |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Phosphor Bronze / Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel shaft with integral sleeve /Carbon Steel shaft with SS sleeve |
Strainers | Stainless steel |
Discharge casing | Cast Iron (FG 200) |
Suction bracket | Cast Iron (FG 200) |
Impeller | Cast Iron (FG 200) (Optional – Bronze) |
Range of performance
PARTICULARS | DETAILS |
Power Range | 3.0 to 30.0 HP |
Voltage Range | 340V- 440V, AC Three phase , 50Hz |
Speed (rpm) | 2900 |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 90 m |
Discharge | Maximum 2640 lpm |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 20 bar |
Sand content | maximum ,50 PPM |
Openwell Submersible Pumpsets
Three Phase Openwell Submersible Pumpsets
Agricultural Openwell Submersible Pumpsets
Product Description
“NEC” OPENWELL SUBMERSIBLE PUMPSETS offer the convenience of not having to change the position of the pump with changing water levels in the well. They are rugged and efficient. They are reliable and are built to withstand tough operating conditions like low voltages, etc.
Performance Chart
Applications
- Deep or shallow openwell pumping with suction lift
- River and canal lift irrigation pumping
- Pressure boosting applications.
- Public water supply to large residence areas and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals etc
- Dewatering of mines
- Industrial water supply and transfer
- Fountains
Features
- Energy efficient motor
- Low operating cost
- Rigid cast iron motor frame, impeller and volute casing
- Three phase water-filled submersible induction motor with easily rewindable stator
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | Water-filled Squirrel cage Induction motor |
Stator Frame | Cast Iron (FG 200) |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Phosphor Bronze / Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel shaft with integral sleeve /Carbon Steel shaft with SS sleeve |
Strainers | Stainless steel |
Discharge casing | Cast Iron (FG 200) |
Suction bracket | Cast Iron (FG 200) |
Impeller | Cast Iron (FG 200) (Optional – Bronze) |
Range of performance
PARTICULARS | DETAILS |
Power Range | 3.0 to 30.0 HP |
Voltage Range | 340V- 440V, AC Three phase , 50Hz |
Speed (rpm) | 2900 |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 90 m |
Discharge | Maximum 2640 lpm |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 20 bar |
Sand content | maximum ,50 PPM |
Openwell Submersible Pumpsets
Three Phase Openwell Submersible Pumpsets
Agricultural Openwell Submersible Pumpsets
Product Description
“NEC” OPENWELL SUBMERSIBLE PUMPSETS offer the convenience of not having to change the position of the pump with changing water levels in the well. They are rugged and efficient. They are reliable and are built to withstand tough operating conditions like low voltages, etc.
Performance Chart
Applications
- Deep or shallow openwell pumping with suction lift
- River and canal lift irrigation pumping
- Pressure boosting applications.
- Public water supply to large residence areas and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals etc
- Dewatering of mines
- Industrial water supply and transfer
- Fountains
Features
- Energy efficient motor
- Low operating cost
- Rigid cast iron motor frame, impeller and volute casing
- Three phase water-filled submersible induction motor with easily rewindable stator
Material of Constructions
PARTICULARS | DETAILS |
MOTOR | Water-filled Squirrel cage Induction motor |
Stator Frame | Cast Iron (FG 200) |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Phosphor Bronze / Carbon |
Diaphragm | Nitryle Rubber |
Shaft | Stainless steel shaft with integral sleeve /Carbon Steel shaft with SS sleeve |
Strainers | Stainless steel |
Discharge casing | Cast Iron (FG 200) |
Suction bracket | Cast Iron (FG 200) |
Impeller | Cast Iron (FG 200) (Optional – Bronze) |
Range of performance
PARTICULARS | DETAILS |
Power Range | 3.0 to 30.0 HP |
Voltage Range | 340V- 440V, AC Three phase , 50Hz |
Speed (rpm) | 2900 |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 90 m |
Discharge | Maximum 2640 lpm |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 20 bar |
Sand content | maximum ,50 PPM |
Openwell Submersible Pumpsets
Three Phase Openwell Submersible Pumpsets
Agricultural Openwell Submersible Pumpsets
Product Descriptions
“NEC” Vertical Open-well Submersible pumpsets are easy to install noise free, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operation requirements.
Performance Chart
Vertical Openwell Submersible Pumpsets Three Phase 380 To 415 Volts 50 HZ AC Supply
Applications
- Deep or shallow openwell pumping
- River and canal lift irrigation pumping.
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting Applications
- Public water supply to large residence areas and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Dewatering of mines
- Industrial water supply and transfer
Features
- Energy Efficient motors
- Low operating cost
- Water lubricated motor with easily rewindable stator
- Rigid cast iron motor frame, impeller and volute casing
- Optional bronze impeller on request
- Three phase water-filled submersible induction motor with easily rewindable stator
Material of Constructions
PARTICULARS | DETAILS |
Stator Frame | Cast Iron |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Phosphor Bronze / Carbon / Stainless steel |
Diaphragm | Nitrile Rubber |
Shaft | Stainless steel shaft with integral sleeve |
Strainers | Stainless steel |
Discharge casing | Cast Iron |
Inlet bracket | Cast Iron |
Impeller | Cast Iron / Bronze |
Range of Performance
PARTICULARS | DETAILS |
Power Range | 3.0 to 50.0 HP |
Voltage Range | 340V- 440V, 50Hz AC Three phase |
Speed | 2900RPM |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 128 M |
Discharge | Maximum 3190 LPM |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 20 bar |
Sand Content in Water | Maximum 50 PPM |
Openwell Submersible Pumpsets
Agricultural Openwell Vertical Submersible Pumpsets
Stainless Steel
Product Descriptions
“NEC” Vertical Open-well Submersible pumpsets are easy to install noise free, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operation requirements.
Applications
- Deep or shallow openwell pumping with suction lift
- River and canal lift irrigation pumping
- Pressure boosting applications.
- Public water supply to large residence areas and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals etc
- Dewatering of mines
- Industrial water supply and transfer
- Fountains
Features
- Energy efficient motor
- Low operating cost
- Rigid cast iron motor frame, impeller and volute casing
- Three phase water-filled submersible induction motor with easily rewindable stator
Material of Constructions
PARTICULARS | DETAILS |
Stator Frame | Cast Iron |
Thrust Bearing | Carbon with SS Thrust pad |
Journal Bearings | Phosphor Bronze / Carbon / Stainless steel |
Diaphragm | Nitrile Rubber |
Shaft | Stainless steel shaft with integral sleeve |
Strainers | Stainless steel |
Discharge casing | Cast Iron |
Inlet bracket | Cast Iron |
Impeller | Cast Iron / Bronze |
Range of Performance
PARTICULARS | DETAILS |
Power Range | 3.0 to 10.0 HP |
Voltage Range | 340V- 440V, 50Hz AC Three phase |
Speed | 2900RPM |
Motor Type | Water-filled and water cooled Induction motor |
Head | Maximum 60 M |
Discharge | Maximum 800 LPM |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 20 bar |
Sand Content in Water | Maximum 50 PPM |
Submersible Borewell Pumpsets
Agricultural Borewell Submersible Pumpsets
6″ (150mm) 1300Feet
Product Descriptions
“NEC” “6″ SUBMERSIBLE PUMPSETS are easy to install, noise free, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain a reliable life and provide maintenance free service.
Performance Chart
Applications
- Water extraction from bores of diameter 6″ (150mm) and above
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Dewatering of mines
- Industrial water supply
Features
- Energy efficient motor
- Usage of Low watt In-house Manufactured Stampings
- Low operating cost (Low Power Consumption)
- Water lubricated motor with easily rewindable stator
- Energy Efficient Radial and mixed flow models
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Wide voltage operation to suit all seasons
- Low, Medium, High Voltage operation Motors to suit particular field condition
- Pumpsets with special materials are available on request
Material of Constructions
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitrile Rubber |
Shaft | Carbon steel with SS extension |
Strainers | Stainless steel |
PUMP | ||
Pump shaft | Stainless steel | Stainless steel |
Valve casing | Cast Iron | Cast Iron |
Inlet bracket | Cast Iron | Cast Iron |
Diffuser housing | Cast Iron | Cast Iron |
Diff user | Bronze / SS | Stainless steel |
Bowl | Cast Iron | Cast Iron |
Impeller | Bronze / SS | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 6”and above |
Power Range | 2.0 to 30.0 HP |
Voltage Range | 340V- 440V, AC Three phase , 50Hz |
Voltage Range | 180V – 240V, AC Single phase , 50Hz (Upto 7.5 HP) |
Speed | 2900 RPM |
Motor Type | Water filled and water cooled Induction motor |
Coupling | Key ( Upto 25 HP) / NEC |
Head | Maximum 400 M |
Discharge | Maximum 600 LPM |
No of Stages | Maximum 25 |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 50 bar |
Sand content in water | 50 PPM Max. |
Pump Models | AT,JT,AT-SS |
Motor Models | ST/NST/EMS/EMS* |
Submersible Borewell Pumpsets
Agricultural Borewell Submersible Pumpsets
6″ (150mm) 1300Feet
Product Descriptions
“NEC” “6″ SUBMERSIBLE PUMPSETS are easy to install, noise free, efficient and require minimum maintenance. A wide range of pumps are available to meet diverse operating requirements. Motors are water lubricated and feature robust thrust bearings. Good quality materials are used to obtain a reliable life and provide maintenance free service.
Performance Chart
Applications
- Water extraction from bores of diameter 6″ (150mm) and above
- Irrigation systems for Agriculture including Drip and Sprinkler systems.
- Pressure boosting applications
- Domestic water supply to large residences and multi storied apartments
- Water supply to commercial establishments like Hotels, Lodges and Hospitals
- Dewatering of mines
- Industrial water supply
Features
- Energy efficient motor
- Usage of Low watt In-house Manufactured Stampings
- Low operating cost (Low Power Consumption)
- Water lubricated motor with easily rewindable stator
- Energy Efficient Radial and mixed flow models
- Rubber diaphragm provided at the bottom of the motor to compensate thermal expansion of water
- Wide voltage operation to suit all seasons
- Low, Medium, High Voltage operation Motors to suit particular field condition
- Pumpsets with special materials are available on request
Material of Constructions
MOTOR | |
Stator Shell | Stainless steel |
Thrust Bearing | Carbon with stainless steel segments |
Journal Bearings | Bronze/ Carbon |
Diaphragm | Nitrile Rubber |
Shaft | Carbon steel with SS extension |
Strainers | Stainless steel |
PUMP | ||
Pump shaft | Stainless steel | Stainless steel |
Valve casing | Cast Iron | Cast Iron |
Inlet bracket | Cast Iron | Cast Iron |
Diffuser housing | Cast Iron | Cast Iron |
Diff user | Bronze / SS | Stainless steel |
Bowl | Cast Iron | Cast Iron |
Impeller | Bronze / SS | Stainless steel |
Range of Performance
PARTICULARS | DETAILS |
Bore size min. | 6”and above |
Power Range | 2.0 to 30.0 HP |
Voltage Range | 340V- 440V, AC Three phase , 50Hz |
Voltage Range | 180V – 240V, AC Single phase , 50Hz (Upto 7.5 HP) |
Speed | 2900 RPM |
Motor Type | Water filled and water cooled Induction motor |
Coupling | Key ( Upto 25 HP) / NEC |
Head | Maximum 400 M |
Discharge | Maximum 600 LPM |
No of Stages | Maximum 25 |
Liquid temperature | Maximum 33ºC |
Operating Pressure | 50 bar |
Sand content in water | 50 PPM Max. |
Pump Models | AT,JT,AT-SS |
Motor Models | ST/NST/EMS/EMS* |
NEC Stainless steel Bore well submersibles pumps are suitable for corrosive environments. The weight to power ratio of these pumps is very low compared to conventional cast iron pumps. This facilitates easy handling and low installation cost. The submersible pump unit consists of a centrifugal wet end with one or more impellers with a strainer protected inlet bracket.
We bring forth a huge assortment of Borewell Submersibles for the worldwide clients. Made using superior quality material, our Deep Well Submersibles comply with industrial standards. Our Borewell Submersibles meet all your borehole pumping needs replacing standard surface pumps.
Salient Features
- Water filled motor with easily rewind able stator
- Suitable for various power supplies
- Energy efficient radial and mixed flow models
- Stainless steel stage housings
- Resistant to wearing
- Corrosion resistant
- Energy efficient
- Customized pump sets are available on request
Useful For
- Farming
- Irrigation
- Water supply
The 3″, 4″ Borewell Submersible we manufacture is a perfect blend of technology and high speed. Our 3″, 4″ Borewell Submersibles are praised for offering reliable and efficient performance. The 3″, 4″ Borewell Submersibles offered by us are high on demand in irrigation sector and can be availed at industry leading prices.
We are offering superior quality 5″, 6″, 7″, 8″, 10″ Borewell Submersibles that are made using high grade raw material. The 5″, 6″, 7″, 8″, 10″ Borewell Submersibles offered by us have been proved useful for the farming industry and are designed din compliance with international standards.
Applications:
Submersible pumps are found in many applications. Single stage pumps are used for drainage, sewage pumping, general industrial pumping and slurry pumping. They are also popular with pond filters. Multiple stage submersible pumps are typically lowered down a borehole and most typically used for residential, commercial, municipal and industrial water extraction (abstraction), water wells and in oil wells.
Other uses for submersible pumps include sewage treatment plants, seawater handling, fire fighting (since it is flame retardant cable), water well and deep well drilling, offshore drilling rigs, artificial lifts, mine dewatering, and irrigation systems.
Pumps in electrical hazardous locations used for combustible liquids or for water that may be contaminated with combustible liquids must be designed not to ignite the liquid or vapors.
